Yamaha F100A - Bearing Inspection; Propeller Shaft Housing Inspection; Reverse Gear Inspection

6-11
E
LOWR
PROPELLER SHAFT HOUSING ASSY.
2. Remove:
● Ball bearing
Å For USA and CANADA
ı For worldwide
Slide hammer:
YB-06096
Stopper guide plate:
90890-06501
Stopper guide stand:
90890-06538
Bearing puller:
90890-06535
Claw:
90890-06536
Å
ı
3. Remove:
● Oil seal
● Needle bearing
Needle bearing attachment:
YB-06153/90890-06612
Driver rod:
YB-06071/90890-06652
Reverse gear inspection
1. Inspect:
● Teeth
● Dogs
Wear/damage → Replace.
Bearing inspection
1. Inspect:
● Bearing
Pitting/rumbling → Replace.
Propeller shaft housing inspection
1. Inspect:
● Propeller shaft housing
Cracks/damage → Replace.
