Yamaha F100A - Page 322

7-9
E
BRKT
UPPER CASE ASSY.
EXPLODED DIAGRAM
1
2
3
4
5
7
8
9
10
11
6
12
15
16
13
17
19
20
22
21
23
18
12 × 194 mm
8 × 40 mm
8 × 45 mm
6 × 16 mm
10 × 40 mm
12 × 168 mm
LT
LT
572
LT
LT
572
LT
LT
572
A
A
A
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
14
Step Procedure/Part name Q’ty Service points
9 Washer 2
10 Washer 2
11 Lower mount rubber 2
12 Bolt 4
13 Upper housing 1
14 Gasket 1
15 Rubber gasket 1
16 Rubber seal 1
17 Screw 2
18 Baffle plate 1
Not reusable
