Yamaha F100A - Page 324

7-10
E
BRKT
UPPER CASE ASSY.
EXPLODED DIAGRAM
1
2
3
4
5
7
8
9
10
11
6
12
15
16
13
17
19
20
22
21
23
18
12 × 194 mm
8 × 40 mm
8 × 45 mm
6 × 16 mm
10 × 40 mm
12 × 168 mm
LT
LT
572
LT
LT
572
LT
LT
572
A
A
A
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
14
Step Procedure/Part name Q’ty Service points
19 Damper 1
20 Grommet 1
21 Circlip 1
22 Drive shaft bushing 1
23 Upper case 1
Reverse the disassembly steps for
installation.
