Yamaha F100A - Page 424

8-19
–+
ELEC
E
STARTER MOTOR
EXPLODED DIAGRAM
18
17
11
16
14
12
10
9
19
21
20
24
23
22
29
30
28
27
26
25
2
3
31
4
5
6
7
8
32
1
6 × 120 mm
4 × 14 mm
6 × 52 mm
4 × 20 mm
13
15
Step Procedure/Part name Q’ty Service points
7 Dust seal 1
8 Relay (magnetic switch) 1
9 Bolt 2
10 Screw 2
11 Yoke assy. 1
12 Rear cover 1
13 Thrust washer 1
14 Plate 1
15 Brush holder assy. 1
