Yamaha Scorpio - Page 154

5 - 8
CARB
CARBURETOR
3.Install:
●
Needle jet
To carburetor
N
OTE:
Be sure to insert the slot
a
onto the projection
b
.
4.Install:
●
Needle valve holder
T
R
.
.
Screw (float valve holder):
2 Nm (0.2 m • kg)
5.Install:
●
Float chamber cover
1
T
R
.
.
Screw (float chamber cover):
5 Nm (0.5 m • kg)
6.Install:
●
Piston valve assembly
1
●
Piston valve spring
2
●
Vacuum chamber cover
3
N
OTE:
Match the tab
a
on the rubber diaphragm to
the matching recess
b
in the piston valve.
T
R
.
.
Screw (vacuum chamber cover):
4 Nm (0.4 m • kg)
