6 - 12
CHAS
FRONT BRAKE
FRONT BRAKE
FRONT BRAKE CALIPER
1
Brake caliper
2
Brake pad
3
Brake pad spring
4
Retaining bolt
5
Brake caliper piston
6
Brake caliper piston seal
7
Bleed screw kit
8
Brake caliper bolt
