Yamaha Scorpio - Carburetor; Drive Chain; Left Footrest Bracket

4 - 6
ENG
ENGINE INSTALLATION
2.Install:
●
Tachometer cable
●
Breather hose
3.Install:
●
Clutch cable
4.Install:
●
Ignition coil
●
Spark plug lead cap
CARBURETOR
1.Install:
●
Carburetor
Refer to the “CARBURETOR” section in
CHAPTER 5.
DRIVE CHAIN
1.Install:
●
Drive chain
●
Drive sprocket
●
Lock washer
T
R
.
.
Nut (drive chain):
110 Nm (11.0 m
•
kg)
2.Install:
●
Drive chain case
LEFT FOOTREST BRACKET
1.Install:
●
Left footrest bracket
T
R
.
.
Bolt (shift arm):
10 Nm (1.0 m
•
kg)
Bolt (footrest bracket):
30 Nm (3.0 m
•
kg)
