LUBRICATION POINTS AND LUBRICANT TYPE
LUBRICATION POINTS AND LUBRICANT TYPE
ENGINE
Lubrication Symbol Lubricant type
Oil seal lip
LS
Lithium-soap base grease
O-Ring
LS
Lithium-soap base grease
Bearing
E
Engine oil
Cylinder head bolt/washer
E
Engine oil
Rocker shaft
M
Molybdeum disulfide oil
Crankshaft pin
E
Engine oil
Connecting rod
E
Engine oil
Piston surface
E
Engine oil
Piston pin
E
Engine oil
Camshaft cam lobe/journal
E
Engine oil
Valve stem (IN, EX)
M
Molybdeum disulfide oil
Valve stem end (IN, EX)
M
Molybdeum disulfide oil
Cam chain/cam sprocket
E
Engine oil
Oil pump shaft, rotor (IN, OUT), housing
E
Engine oil
Kick shaft
E
Engine oil
Kick idle sprocket (inside)
E
Engine oil
Kick crank shaft
LS
Lithium-soap base grease
Kick idle gear/kick gear
E
Engine oil
Starter clutch
E
Engine oil
Primary driven gear
E
Engine oil
Push lever axle
M
Molybdeum disulfide oil
Transmission gear (wheel/pinion)
M
Molybdeum disulfide oil
Axle (main/drive)
M
Molybdeum disulfide oil
Shift cam
M
Molybdeum disulfide oil
Shift fork/guide bar
E
Engine oil
Crankcase mating surfaces Yamaha bond No.1215
®
