4 - 8
ENG
ENGINE INSTALLATION
3.Adjust:
●
Throttle cable free play
●
Clutch lever free play
Refer to the “THROTTLE CABLE ADJUST-
MENT”, “CLUTCH ADJUSTMENT” section in
CHAPTER 3.
4.Adjust:
●
Drive chain slack
Refer to the “DRIVE CHAIN SLACK
ADJUSTMENT” section in CHAPTER 3.
Throttle cable free play:
3 ~ 5 mm
Clutch lever free play:
10 ~ 15 mm
Drive chain slack:
20 ~ 30 mm
