YASKAWA FS100 - 1.3 Signal Flow

1 Outline of INFORM
FS100 1.2 Registration of Instructions
1-5
1.2 Registration of Instructions
1.2.1 Registration
Press [INFORM LIST] . while the job content window is shown to register
instructions.
1. Select {JOB} under the main menu
2. Select {JOB}
– The job content window appears.
3. Press [INFORM LIST]
– The job instruction group list dialog box appears.
4. Select the desired instruction group
– The job instruction group list dialog box appears.
5. Select the desired instruction
– The instruction is displayed in the input buffer line.
6. Press [ENTER]
– The instruction displayed in the input buffer line is registered in the
job.
Also, if the instruction must be registered during the job, press
[INSERT] before pressing [ENTER].
SUPPLE
-MENT
Refer to the Operator’s Manual “3.6 Editing Instructions” for
details on editing instructions.
JOB
EDIT
DISPLAY
UTILITY
Main Menu Short Cut
JOB CONTENT
JOB NAME : R1S1
CONTROL GROUP : R1+S1
STEP NO : 004
TOOL : 00
0017 TIMER T=1.000
0018 MOVJ VJ=12.50
0019 MOVJ VJ=50.00
0020 MOVL V=138
0021 MOVL V=138
0022 MOVJ VJ=100.00
0023 DOUT OT#(1) ON
IN/OUT
OTHER
CONTROL
DEVICE
MOTION
ARITH
SHIFT
SAME
PRIOR
=>
JOB
EDIT
DISPLAY
UTILITY
Main Menu
Short Cut
JOB CONTENT
JOB NAME : R1S1
CONTROL GROUP : R1+S1
STEP NO : 004
TOOL : 00
=>
ARATIOF
DOUT
DIN
WAIT
PULSE
IN/OUT
OTHER
CONTROL
DEVICE
MOTION
ARITH
SHIFT
SAME
PRIOR
AOUT
ARATION
=>
DOUT OT#(1) ON
0017 TIMER T=1.000
0018 MOVJ VJ=12.50
0019 MOVJ VJ=50.00
0020 MOVL V=138
0021 MOVL V=138
0022 MOVJ VJ=100.00
0023 DOUT OT#(1) ON
