1 Outline of INFORM
FS100 1.4 Registration of Expression
1-10
1.4.2 Registration
1. Select {JOB} under the main menu
2. Select {JOB}
3. Press [INFORM LIST]
4. Select “ARITH”
5. Select “SET”
6. Press [SELECT]
– The DETAIL EDIT window for the SET instruction appears.
7. Move the cursor to the button beside “SOURCE(TOKEN)”
– The selection dialog box appears.
SET
JOB
EDIT
DISPLAY
UTILITY
Main Menu Short Cut
DETAIL EDIT
=>
SET B000 1
DESTINATION B000
SOURCE (TOKEN) 1
SET
JOB
EDIT
DISPLAY
UTILITY
Main Menu Short Cut
DETAIL EDIT
DESTINATION B000
SOURCE (TOKEN) EXPRESS
=>
SET B000 1
[ ]
[ ]
[ ]
[ ]
I
I
CONSTANT
B
B
D
D
R
R
EXPRESS
