2 INFORM Explanation
FS100 2.1 I/O Instructions : AOUT
2-14
AOUT
Outputs the set voltage value to the general-purpose analog output port.
1. AO# (Analog output port number)
Add the following tag.
2. Output voltage value
Add the following tag.
(1) SET I000 970
AOUT AO#(1) I000
The voltage of 9.7 V is output to the analog output port No. 1.
SUBSET STANDARD EXPANDED
Not available Available Available
Function
Construction
AOUT AO# (
Analog output
port No.
)
Output voltage
value (V)
1 2
END
Explanation
No Tag Explanation Note
1 AO# (Analog output
port number)
Specifies the number of the analog output port to which
the set voltage value is output.
No.: 1 to 40
Variable B/I/D/LB/LI/LD
can be used.
No. Tag Explanation Note
2 Output voltage value Specifies the output voltage value. Voltage value:
-10.00 to +10.00
Variable I/LI/I[]/LI[] can
be used.
(Units: 0.01 V)
