WARNING
• Before operating the manipulator, check that servo power is turned
OFF when the emergency stop buttons on the front door of the
DX200 and the programming pendant are pressed.
When the servo power is turned off, the SERVO ON LED on the
programing pendant is turned off.
Injury or damage to machinery may result if the emergency stop circuit
cannot stop the manipulator during an emergency. The manipulator
should not be used if the emergency stop buttons do not function.
Fig. : Emergency Stop Button
• In the case of not using the programming pendant, be sure to
supply the emergency stop button on the equipment. Then before
operating the manipulator, check to be sure that the servo power is
turned OFF by pressing the emergency stop button.
Connect the external emergency stop button to the 5-6 pin and 16-
17 pin of the robot system signal connector (CN2).
• Upon shipment of the FS100, this signal is connected by a jumper
cable in the dummy connector. To use the signal, make sure to
prepare a new connector, and then input it.
If the signal is input with the jumper cable connected, it does not
function, which may result in personal injury or equipment damage.
• Once the emergency stop button is released, clear the cell of all
items which could interfere with the operation of the manipulator.
Then turn the servo power ON.
Injury may result from unintentional or unexpected manipulator motion.
Fig. : Release of EM
TURN
• Observe the following precautions when performing teaching
operations within the P-point maximum envelope of the
manipulator:
– Be sure to use a lockout device to the safeguarding when going
inside.
Also, display the sign that the operation is being performed inside
the safeguarding and make sure no one closes the safeguarding.
– View the manipulator from the front whenever possible.
– Always follow the predetermined operating procedure.
– Ensure that you have a safe place to retreat in case of
emergency.
Improper or unintended manipulator operation may result in injury.
The emergency stop button is located on the programing pendant.
