2 INFORM Explanation
FS100 2.2 Control Instruction : DIALSB
2-70
2. B Variable number / LB Variable number / B [Array
number] / LB [Array number]: Message Y coordi-
nates
Add the following tag.
3. S Variable number / LS Variable number / S [Array
number] / LS [Array number]: Message character
string
Add the following tag.
4. B Variable number / LB Variable number / B [Array
number] / LB [Array number]: Button X coordinates
Make sure to add the following tag for the first DIALSB in the DIALOG
instruction.
For the second and after, the following tag can be added or omitted.
5. B Variable number / LB Variable number / B [Array
number] / LB [Array number]: Button Y coordinates
Make sure to add the following tag for the first DIALSB in the DIALOG
instruction.
For the second and after, the following tag can be added or omitted.
No Tag Explanation Note
2 B Variable number/
LB Variable number/
B [Array number]/
LB [Array number]
Specifies the byte type variable number.
No Tag Explanation Note
3 S Variable number/
LS Variable number/
S [Array number]/
LS [Array number]
Specifies the character string type variable number.
No Tag Explanation Note
4 B Variable number/
LB Variable number/
B [Array number]/
LB [Array number]
Specifies the byte type variable number.
No Tag Explanation Note
5 B Variable number/
LB Variable number/
B [Array number]/
LB [Array number]
Specifies the byte type variable number.
