YASKAWA MP2200 User Manual

iii
Using this Manual
Please read this manual to ensure correct usage of the SVB-01 Module of MP2200/MP2300.
Keep this manual in a safe place for future reference.
 Basic Terms
Unless otherwise specified, the following definitions are used:
• SVA-01: Motion Module SVA-01
• SVB-01: Motion Module SVB-01
• MP2200/MP2300: Machine Controller MP2200/MP2300
• SVR: Virtual Motion Module SVR
• PC: Programmable Logic Controller
• PP: Programming Panel
• MPE720: The Programming Device Software or a Programming Device (i.e., a
personal
computer) running the Programming Device Software
• SERVOPACK Series Names and Abbreviations
The SERVOPACKS applicable to the SVA-01 and SVB-01 Motion Modules are listed in the
following table. The series names and abbreviations used in this manual are limited to those
for the SERVOPACK model numbers listed below.
Series Name Abbreviation
SERVOPACKs Applicable to
the SVB-01
SERVOPACKs Applicable to
the SVA-01
Σ Series Σ
SGD
-
N,
SGDB-AN
SGDA
-
S,
SGDB
-
AD-,
SGDB
-
DD
Σ-
II
Series Σ-
II
SGDH-E + NS100,
SGDH-E + NS115
SGDM
-
DA,
SGDM
-
AD,
SGDH
-
DE,
SGDH
-
AE,
SGDH
-
E
Σ-
III
Series Σ-
III
SGDS-1
SGDS
-
-01,
SGDS
-
-02,
SGDS
-
05,
SGDS
-
A,
SGDS
-
F
