YASKAWA MP2200

2.2
SVA-01 Module Specifications and Connections
2-19
2.2.3 Module Connections
This section explains the connections for the SVA-01 Module.
( 1 ) Connector and Cable Specifications
[ a ] Servo Interface Connectors (CN1 and CN2)
[ b ] 24-V Input Connector (CN3)
This connector connects the SVA-01 Module to +24 VDC as a Servo I/O power supply.
A screw terminal connector is used (BL3.5/2F-AU manufactured by Weidmuller).
[ c ] Servo Connector Specifications
The following table shows the connector specifications.
These connectors connect the SVA-01 Module to two SERVOPACKs.
They are connected using the following standard cable.
•
JEPMC-W2040-

(For SGDH, SGDM, and SGDS SERVOPACKs)
（Note） The customer must provide cables for the SGDA and SGDB SERVOPACKs.
Pin No. Signal Name Name
2
24V +24 VDC input
1
0V 0 V
DC IN
ON
+24V
Name
Connector
Name
No. of
Pins
Connector Model
Cable Model Numbers
Module Side Cable Side
Manufacture
r
Servo Interface
Connector 1 and
Connector 2
CN1
CN2
36 10236-52A2JL
•
Connector body:
10136-3000VE
•
Shell:
10336-52A0-008
(
Screw locking
)
10336-52F0-008
(
One-touch locking
)
3M
JEPMC-W2040-

(For the SGDH/
SGDM/SGDS
SERVOPACKs
)
24-V Input
Connector
CN3
2 −
• BL3.5/2F-AU
Weidmuller
The CN3 connector is
included with the SVA-
01 Module, but a cable is
not included. The user
must connect the cable.
