2.2
SVA-01 Module Specifications and Connections
2-15
Mechanical
Operating
Conditions
Vibration Resistance
Conforms to JIS B 3502.
Vibration amplitude/acceleration:
10
≤
f < 57 Hz, Single-amplitude of 0.075 mm
57
≤
f
≤
150 Hz, Fixed acceleration of 9.8 m/s
2
10 sweeps (1 sweep = 1 octave per minute) each in the X, Y, and Z directions
Shock Resistance
Conforms to JIS B 3502.
Peak acceleration of 147 m/s
2
twice for 11 ms each in the X, Y, and Z
directions
Electrical Operating
Conditions
Noise Resistance
Conforms to EN 61000-6-2 and EN 55011 (Group 1 Class A).
Power supply noise (FT noise): 2 kV min., for one minute
Radiation noise (FT noise): 1 kV min., for one minute
Installation
Requirements
Ground
Ground to 100
Ω
max.
Cooling Method
Natural cooling
Dimensions (mm)
125
×
95 (H
×
D)
Mass
80 g
(cont’d)
Item Specifications
