User Parameter Tables
4-47
4
* The factory setting will change when the control method is change. (The Close Loop Vector factory setting is given.)
S1-23
Torque com-
pensation
gain during
lowering
Sets the torque compensation
gain at lowering.
0.500
to
10.000
1.000 No No No A 6AAH -
TorqComp-
gain@low
S1-24
Torque com-
pensation
bias during
raising
Sets the torque compensation
bias at raising.
-200.0
to
+200.0
0.0% No No No A 6ABH -
TorqComp-
Bias@rai
S1-25
Torque com-
pensation
bias during
lowering
Sets the torque compensation
bias at lowering.
-200.0
to
+200.0
0.0% No No No A 6ACH -
TorqComp-
Bias@low
S1-26
Dwell speed
reference
Hold speed reference when
the load is heavy.The fre-
quency reference follows the
C1-07 acceleration 4 setting
time.
Acceleration time will be
changed when the motor speed
exceeds the C1-11 setting fre-
quency.
0.0
to 120.0
0.0Hz No A A A 6ADH -
DWELL
speed
S1-27
Frequency
detection at
stop
S1-27 setting is enable at stop-
ping.
Multi-function digital
ouput(setting 42) is closed
when output frequency or
motor speed( CLV)is below
S1-27 setting .This signal is
used for lift door control.
0.0
to 120.0
0.0Hz No A A A 6ADH -
Freq Det
@Stop
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
