YASKAWA Varispeed L7 User Manual

Digital Operator/Monitor Functions
5-57
5
Storing Inverter set values in the Digital Operator/Monitor (READ)
To store Inverter set values in the Digital Operator/Monitor use the following method.
If an error is displayed, press any key to cancel the error display and return to the o3-01 display. Refer to
page 6-16, Digital Operator/Monitor Copy Function Faults for corrective actions.
Table 5.1 READ Function Procedure
Step
No.
Explanation
Digital Operator/Monitor Dis-
play
1 Press the Menu Key and select advanced programming mode.
2 Press the DATA/ENTER Key.
3
Press the Increment and Decrement Key until parameter o3-01 is displayed (Copy Function
Selection).
4 Press the DATA/ENTER Key and select the constants setting display.
5 Change the set value to 1 using the Increment Key.
6 Set the changed data using the DATA/ENTER Key. The READ function will start.
7 If the READ function ends normally, “End” is displayed on the Digital Operator/Monitor.
8 The display returns to o3-01 when a key is pressed.
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1 - 00=1
Select Language
COPY Function
-ADV-
o3 - 01=0
Copy Funtion Sel
Copy Function Sel
-ADV-
o3
-01= 0
COPY SELECT
*0*
Copy Function Sel
-ADV-
o3
-01=
1
*0*
INV OP READ
READ
-ADV-
INV OP
READING
READ
-ADV-
READ COMPLETE
Copy Function Sel
-ADV-
o3
-
01=0
COPY SELECT
*0*
