5-58
Writing Parameter Set Values Stored in the Digital Operator/Monitor to the Inverter
(COPY)
To write parameter set values stored in the Digital Operator/Monitor to the Inverter, use the following method.
If an error is displayed, set the parameters again. Refer to page 6-16, Digital Operator/Monitor Copy Function
Faults for corrective actions.
Table 5.2 COPY Function Procedure
Step
No.
Explanation
Digital Operator/Monitor Dis-
play
1 Press the MENU Key and select advanced programming mode.
2 Press the DATA/ENTER Key.
3
Press the Increment and Decrement Key until parameter o3-01 is displayed (Copy Function
Selection).
4 Press the DATA/ENTER Key and select the constants setting display.
5 Change the set value to 2 using the Increment Key.
6 Set the changed data using the DATA/ENTER Key. The COPY function will start.
7 If the COPY function ends normally, “End” is displayed on the Digital Operator/Monitor.
8 The display returns to o3-01 when a key is pressed.
** Main Menu **
-ADV-
Programming
Initialization
-ADV-
A1
- 00 = 1
Select Language
COPY Function
-ADV-
o3 - 01 = 0
Copy Funtion Sel
Copy Function Sel
-ADV-
o3-01= 0
COPY SELECT
*0*
Copy Function Sel
-ADV-
o3-01= 2
OP INV WRITE
*0*
COPY
-ADV-
OP INV
COPYING
COPY
-ADV-
COPY COMPLETE
Copy Function Sel
-ADV-
o3
-
01 =0
COPY SELECT
*0*
