User Constants
9-11
9
H3-06 AI-14B CH3 input gain 100.0%
H3-07 AI-14B CH3 input bias 0.0%
H3-08 AI-14B CH2 signal level selection 2
H3-09 AI-14B CH2 function selection 3
H3-10 AI-14B CH2 input gain 100.0 %
H3-11 AI-14B CH2 input bias 0.0 %
H3-12 Analog input filter time constant for the AI-14B 0.03 s
H3-15 Terminal A1 function selection 0
H3-16 Terminal A1 input gain 100.0%
H3-17 Terminal A1 input bias 0.0%
H5-01 Station address 1F
H5-02 Communication speed selection 3
H5-03 Communication parity selection 0
H5-04 Stopping method after communication error 3
H5-05 Communication error detection selection 1
H5-06 Send wait time 5 ms
H5-07 RTS control ON/OFF 1
L1-01 Motor protection selection 1
L1-02 Motor protection time constant 1.0 min
L2-05 Undervoltage detection level 190 V
L2-11 Battery Voltage 0V
L3-01 Stall prevention selection during accel 1
L3-02 Stall prevention level during accel 150 %
L3-05 Stall prevention selection during running 1
L3-06 Stall prevention level during running 150 %
L4-01 Speed agreement detection level 0.0 Hz
L4-02 Speed agreement detection width 2.0 Hz
L4-03 Speed agreement detection level (+/-) 0.0 Hz
L4-04 Speed agreement detection width (+/-) 2.0 Hz
L4-05 Operation when frequency reference is missing 0
L4-06 Frequency reference value at frequency reference loss 80 %
L5-01 Number of auto restart attempts 2
L5-02 Auto restart operation selection 1
L6-01 Torque detection selection 1 0
L6-02 Torque detection level 1 150 %
L6-03 Torque detection time 1 0.1 s
L6-04 Torque detection selection 2 0
Table 9.1 User Constants
