F1-14 PG open-circuit detection delay time 1.0 s
F4-01 Channel 1 monitor selection 2
F4-02 Channel 1 gain 100.0%
F4-03 Channel 2 monitor selection 3
F4-04 Channel 2 gain 50.0%
F4-05 Channel 1 output monitor bias 0.0%
F4-06 Channel 2 output monitor bias 0.0%
F4-07 Analog output signal level for channel 1 0
F4-08 Analog output signal level for channel 2 0
F5-01 Channel 1 output selection 0
F5-02 Channel 2 output selection 1
F5-03 Channel 3 output selection 2
F5-04 Channel 4 output selection 4
F5-05 Channel 5 output selection 6
F5-06 Channel 6 output selection 37
F5-07 Channel 7 output selection 0F
F5-08 Channel 8 output selection 0F
F5-09 DO-08 output mode selection 0
F6-01 Operation selection after communications error 1
F6-02 Input level of external error from Communications Option Card 0
F6-03 Stopping method for external error from Communications Option Card 1
F6-04 Trace sampling from Communications Option Card 0
F6-05 Current monitor unit selection 0
F6-06 Torque reference/torque limit selection from communications option card 0
H1-01 Terminal S3 function selection 24
H1-02 Terminal S4 function selection 14
H1-03 Terminal S5 function selection 3
H1-04 Terminal S6 function selection 4
H1-05 Terminal S7 function selection 6
H2-01 Terminal M1-M2 function selection 40
H2-02 Terminal M3-M4 function selection 41
H2-03 Terminal M5-M6 function selection 6
H3-01 Frequency reference AI-14B CH1signal level selection 0
H3-02 Frequency reference AI-14B CH1 input gain 100.0 %
H3-03 Frequency referenceAI-14B CH1 input bias 0.0 %
H3-04 AI-14B CH3 signal level selection 0
H3-05 AI-14B CH3 function selection 2
Table 9.1 User Constants
No. Name
Factory
Setting
Setting
