User Constants
9-9
9
d1-13
Frequency reference 13 V
r
0.00 Hz
d1-14 Frequency reference 14 Inspection 25 Hz
d1-17 Jog frequency reference / Leveling speed 4.00 Hz
d1-18 Speed priority selection 1
d6-03 Field forcing function selection 0
d6-06 Field forcing function Limit 400 %
E1-01 Input voltage setting *4
E1-04 Max. output frequency (FMAX) 60.0 Hz
E1-05 Max. output voltage (VMAX) *4
E1-06 Base frequency (FA) 60.0 Hz
E1-07 Mid. output frequency (FB) *4
E1-08 Mid. output frequency voltage (VB) *4
E1-09 Min. output frequency (FMIN) *4
E1-10 Min. output frequency voltage (VMIN) *4
E1-13 Base voltage (VBASE) 0.0 V
E2-01 Motor rated current *4
E2-02 Motor rated slip *4
E2-03 Motor no-load current *4
E2-04 Number of motor poles 4 poles
E2-05 Motor line-to-line resistance *4
E2-06 Motor leak inductance *4
E2-07 Motor iron saturation coefficient 1 0.50
E2-08 Motor iron saturation coefficient 2 0.75
E2-09 Monitor mechanical losses 0.0 %
E2-10 Motor iron loss for torque compensation *4
E2-11 Motor rated output power *4
F1-01 PG constant 1024
F1-02 Operation selection at PG open circuit (PGO) 1
F1-03 Operation selection at overspeed (OS) 1
F1-04 Operation selection at deviation 3
F1-05 PG rotation 0
F1-06 PG division rate (PG pulse monitor) 1
F1-08 Overspeed detection level 115 %
F1-09 Overspeed detection delay time 0.0 s
F1-10 Excessive speed deviation detection level 10 %
F1-11 Excessive speed deviation detection delay time 0.5 s
Table 9.1 User Constants
No. Name
Factory
Setting
Setting
