4-24
F1-06
PG division
rate (PG
pulse moni-
tor)
Sets the division ratio for the
PG speed control card pulse
output.
Division ratio = (1+ n) /m
(n=0 or 1 m=1 to 32)
The first digit of the value of
F1-06 stands for n, the second
and the third stands for m.
This parameter is effective
only when a PG-B2 is used.
The possible division ratio set-
tings are: 1/32 ≤ F1-06
≤ 1.
1 to 132 1 No No No A 385H 5-63
PG Output
Ratio
F1-08
Overspeed
detection
level
Sets the overspeed detection
method.
Motor speeds that continue to
exceed the value set in F1-08
(set as a percentage of the
maximum output frequency)
for the time set in F1-09 are
detected as overspeed faults.
0 to 120 115% No No No A 387H 5-63
PG Overspd
Level
F1-09
Overspeed
detection
delay time
0.0 to
2.0
0.0 s No No No A 388H 5-63
PG Overspd
F1-10
Excessive
speed devia-
tion detec-
tion level
Sets the speed deviation detec-
tion method.
Any speed deviation above the
F1-10 set level (set as a per-
centage of the maximum out-
put frequency) that continues
for the time set in F1-11 is
detected as a speed deviation.
The speed deviation is the dif-
ference between actual motor
speed and the speed reference
command.
0 to 50 10% No No No A 389H 5-63
PG Deviate
Level
F1-11
Excessive
speed devia-
tion detec-
tion delay
time
0.0 to
10.0
0.5 s No No No A 38AH 5-63
PG Deviate
Time
F1-14
PG open-cir-
cuit detec-
tion delay
time
Used to set the PG disconnec-
tion detection time. PGO will
be detected if the detection
time exceeds the set time.
0.0 to
10.0
1.0 s No No No A 38DH 5-63
PGO Detect
Time
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
