16.10 General Specifications
Item Specifications
Safety standard* Complying standard :EN61010
• Overvoltage category II
• Pollution degree 2
Emission* Complying Standard : EN55011:Class A, Group1
This is a Class A product(for industrial environment). In a domestic environment, this product may
cause radio interference in which case the user may be required to take adequate measures.
• Cable conditions for DL1540/DL1540L
• External trigger/clock input terminal
Connected BNC cable(3D2W), with both side’s Ferrite Cores(TDK:ZCAT2035-0930A)
•Trigger output terminal
Same as above for the External trigger/clock input terminal
• Connecter for half pitch interface
Connected the cable B9920TA(the dedicated cable for RS-232-C Unit-700927)
• Cable conditions for DL1520/DL1520L
• Connector for RS-232-C interface (for suffix code -C2)
Connected RS-232-C shielded cable, with both side’s Ferrite Cores(TDK:ZCAT2035-0930A)
• Connector for Centronics interface (for suffix code -C3)
Connected the cable B9916TB(the dedicated cable for suffix code -C3)
• Connecter for half pitch interface (for the SCSI interface, on DL1520L with suffix code -C4)
Use a cable less than 3 m long with a characteristic impedance between 90 and 132 Ω. Also,
attach a ferrite core (TDK:ZCAT2035-0930A) on each end of the cable.
Immunity* Complying Standard : EN50082-2:1995
• Susceptibility under immunity condition
Noise increase : < ±15 mV
SCSI interface : No effect
•Testing Condition
100 Msps 5 mV/div PeakDetect(Envelope)Mode 20 MHzBWL, Channel Input terminated with
50 Ω.
Standard operating conditions Ambient temperature : 23 ±2 °C
Ambient humidity : 55 ±10 % RH
Power voltage and frequency fluctuation : Less than 1 % of the rated voltage/frequency
Warm-up time 30 min. or more
Storage conditions Temperature : –20 to 60 °C
Humidity : 20 to 85 % RH (no condensation allowed)
Operating conditions Temperature : 5 to 40 °C
Humidity : 20 to 85 % RH (without printer)
: 35 to 85 % RH (with printer) (No condensation allowed in either case)
Storage altitude 3000 m or below
Operating altitude 2000 m or below
Rated supply voltage DL1540, DL1540L (for suffix code -1 and -5) : 100 to 120 VAC/200 to 240 VAC
DL1520, DL1520L (for suffix code -1) : 100 to 120 VAC
DL1520, DL1520L (for suffix code -5) : 200 to 240 VAC
Permitted supply voltage range DL1540, DL1540L (for suffix code -1 and -5) : 90 to 132 VAC/180 to 264 VAC
DL1520, DL1520L (for suffix code -1) : 90 to 132 VAC
DL1520, DL1520L (for suffix code -5) : 180 to 264 VAC
Rated supply voltage frequency 50/60 Hz
Permitted supply voltage frequency 48 to 63 Hz
Power Supply Fuse DL1540, DL1540L (for suffix code -1 and -5) : 250 V, 3.15 A, Time lag, VDE/SEMKO approved
DL1520, DL1520L (for suffix code -1) : 250 V, 3 A, Time lag, UL/CSA approved
DL1520, DL1520L (for suffix code -5) : 250 V, 2 A, Time lag, VDE/SEMKO approved
Maximum power consumption DL1540, DL1540L (for suffix code -1 and -5) : 220 VA/280 VA
(when the built-in printer is used) DL1520, DL1520L (for suffix code -1) : 130 VA
DL1520, DL1520L (for suffix code -5) : 140 VA
(when the built-in printer is not used; refer to page 3-5)
* Applies to products manufactured after Jan. 1997 having the CE Mark. For all other products, please contact your nearest YOKOGAWA
representative as listed on the back cover of this manual.
