IM 701510-01E
15-3
Troubleshooting, Maintenance
and Inspection
15
15.2 Error Messages and Corrective Actions
Message Type
There are two types of messages which are displayed on the screen.
Status message
Displays the currently executing operation and the results.
Error/warning message
Displayed if an invalid setting has been made or if the instrument is defective.
When Maintenance Service is Required
Contact your nearest YOKOGAWA representative as listed on the back cover of this
manual.
Status Message
No. Message Reference Page
0 Calibration is in progress. 4-6
1 Auto setup is in progress. 4-2
2 Saving file is in progress. 12-4, 9, 11
3 Loading file is in progress. 12-4, 9
4 Deleting file is in progress. 12-14
5 Disk formatting is in progress. 12-2
6A directory list is currently being created. 12-3
7 Set-up data has been stored in the internal memory. 11-3
8 Displayed waveform has been stored in the internal memory. 11-1
9 Printer output is aborted. 10-3, 10
10 GO/NO-GO is aborted. 9-5, 6, 10, 11
11 Trigger action is aborted. 6-14, 15
12 DATA output is aborted. 13-2
13 Exit from GO/NO-GO mode. 9-5, 6, 10, 11
14 Execution completed. –
Error/Warning Message
In addition to the messages given below, there are also some other error/warning messages
(code Nos. 100 to 500). These messages are described in the Communication Interface
User’s Manual (IM701510-11E).
If an error message other than those given below is displayed, the instrument may be
defective. In this case, inform your nearest YOKOGAWA representative and inform him the
number of the message which appears.
No. Message Reference Page
601 Invalid file name 4-8
602 No floppy disk inserted. 12-1
603 No SCSI —
604 Storage media is defective. 12-3
605 File not found. —
606 Floppy disk is write-protected. —
609 File name already exists. —
610 Reserved file name or illegal character. 4-8
611 Directory is full. No more files can be created. 12-3
612 Insufficient space for creating a file. 12-3
614 File is write-protected. 12-14
615 Formatting error. —
646-654 Storage media is defective. 12-3
656 File attribute error. —
659 It is not possible to load the file using this ROM version or this Model. —
662 It is not possible to load an ASCII type file. —
675 (For DL1520L/DL1540L)
ACQ data (BIN/ASCII) cannnot be saved since insufficient space is available (less than 20K) —
To Next Page
