YOKOGAWA DL 1540 User Manual

App-13
IM 701510-01E
Appendix
App
$MGroup1
MTraceNumber 1 : Number of waveforms in this group
MBlockNumber 3 : Number of blocks in this group
MTraceName Ch2 : Waveform ID within group
StartBlockNo. 1 : First block of saved data in group
StartPointNo. 1 : Data start point in first block
EndBlockNo. 3 : Last block of saved data in group
EndPointNo. 10024 : Data end point in last block of group
*1: Endian mode for storage (becomes "Big" on DL1500 series)
Big : Data for Motorola 68000 series.
Ltl : Data for Intel 86 series.
*2: Binary file storage format (becomes "Trace" on DL1500 series)
Trace : Groups into blocks, each block for a single waveform.
Block : Groups into blocks, each block for data sampled at the same time.
*3: Maximum number of blocks per group (or repetitions in the case of single (N) trigger
mode)
Maximum number of blocks applies if the number of blocks varies from waveform to
waveform.
*4: Y axis conversion equation for each waveform
Y axis value = VResolution x Raw data + VOffset
*5: Data type
ISn: n-byte signed integer ¨ “BIN”, “P-P”
FS10 : 10-byte signed real number ¨ “FLOAT”
*6: X axis conversion equation for each waveform
X axis value = HResolution ¥ (Data No. - 1) + HOffset
Binary Data
The data and file structures vary according to the type of data to be saved.
Data structure
Data other than averaging data
15 14 13 12 11 10 9 8 7

654
0
3
0
2
0
1
0
0
0
Code
Averaging data
15 14 13 12 11 10 9876543210
Code
File structure
• BIN
BIN (waveform data)
Control information
Appendix 5 Output Data Format used when Saving Waveform Data (Example DL1540L)
