YOKOGAWA DL 1540 User Manual

IM 701510-01E
16-1
Specifications
16
16.1 Input Section
Item Specifications
No. of input channels 4 (CH1 to CH4), 2 (CH1/CH2) for DL1520/DL1520L : analog input
Input coupling AC, DC, GND
Input connector BNC connector
Input impedance 1 MΩ ±1.5%, approx. 25 pF
Voltage axis sensitivity setting range*
1
1 mV/div to 5 V/div (in multiples of 1, 2 and 5), 2 m V/div to 5 V/div for DL1520/DL1520L
Maximum input voltage 250 V(DC+ACpeak) or 177 Vrms
(when frequency is 1 kHz or lower) CAT I and II
Maximum DC offset setting range 5 V/div to 1 V/div : ±100 V
(probe attenuation 1:1) 500 mV/div to 100 mV/div : ±10 V
50 mV/div to 1 mV/div : ±1 V (50 mV/div to 2 mV/div for DL1520/DL1520L)
Vertical axis accuracy
DC accuracy *
1
1 mv/div : ± (5 % of 8 div + 1 LSB)(1 mV/div is available on DL1540/DL1540L)
100 mv/div : ± (1.5 % of 8 div + 1 LSB)
others : ± (2.5 % of 8 div + 1 LSB)
Offset voltage axis accuracy *
2
5 V/div to 1 V/div : ± (2.5 % of setting + 20 mV)
500 mV/div to 100 mV/div : ± (1 % of setting + 2 mV)
50 mV/div to 1 mV/div : ± (2.5 % of setting + 0.2 mV)(1 mV/div is available on DL1540/DL1540L)
Frequency characteristics *
2
5 V/div to 10 mV/div Repetitive : DC to 150 MHz
(–3 dB point when sine wave of Single : DC to 80 MHz (when using CH1/2 simultaneously
amplitude ±4 div is input) measuring for DL1540/DL1540L) (CH1 only for
DL1520/DL1520L)
: DC to 40 MHz (when using 3/4 Ch. simultaneously
measuring for DL1540/DL1540L) (when using 2 Ch.
simultaneously measuring for DL1520/DL1520L.)
5 mV/div Repetitive : DC to 80 MHz
Single : DC to 80 MHz (when using CH1/2 simultaneously
measuring for DL1540/DL1540L) (CH1 only for
DL1520/DL1520L)
: DC to 40 MHz (when using 3/4 Ch. simultaneously
measuring for DL1540/DL1540L) (when using 2 Ch.
simultaneously measuring for DL1520/DL1520L)
2 mV/div, 1 mV/div : DC to 20 MHz (1 mV/div is available on DL1540/
DL1540L)
–3 dB point when AC coupling used 10 Hz or below (1 Hz or below in case the accessory 10:1 probe is being used)
Inter-channel skew 2 ns or less
(under the same conditions)
Residual noise level *
3
±0.7 mV or ±0.12 div (typical value*
5
), whichever greater
Inter-channel isolation –40 dB (typical value*
5
)
(same voltage axis sensitivity, DC to 150 MHz)
A/D converter resolution 8 bit (25 LSB/div)
Probe attenuation 1:1, 10:1, 100:1, 1000:1
Bandwidth limit Bandwidth limit can be turned ON/OFF for 20 MHz
Maximum sampling rate real-time sampling mode
2 channels measurement : 200 MS/s (CH1 for DL1520/DL1520L, CH1/CH2 for DL1540/DL1540L)
3/4 channels measurement : 100 MS/s (when using 2 Ch. simultaneously measuring for DL1520/1DL1520L.)
repetitive sampling mode : 20 GS/s
Maximum Record length (For DL1520) (For DL1520L)
When in roll mode : 20 K (10 K*
4
)W/CH 1 channel measurement : 1 MW/CH(for CH1 only)
In other cases : 10 K (10 K*
4
)W/CH 2 channels measurement : 400 KW/CH
(For DL1540)
When trigger mode is single long mode
2 channels measurement : 120 K (100 K*
4
)W/CH (for CH1/CH2 only)
3/4 channels measurement: 56 K (50 K*
4
)W/CH
When in roll mode : 20 K (10 K*
4
)W/CH
In other cases : 10 K (10 K*
4
)W/CH
(For DL1540L)
2 channels measurement : 2 MW/CH (for CH1/CH2 only)
3/4 channels measurement : 1 MW/CH
*1 Voltage axis sensitivity of 1 mV/div can be achieved by digital zooming (2 mV/div x 2).
*2 Measured with the internal clock selected as the timebase and the voltage axis sensitivity set to “CAL”, after calibration following a 30-
minute warm-up, under the standard operating conditions stipulated on page 16-8.
*3 Measured with the input short-circuited, record length set to 10 KW, acquisition mode set to normal mode and accumulation function OFF.
*4 Record length displayed on the screen
*5 Typical values are described in terms of typical of average performance. However, they cannot be guaranteed.
