YOKOGAWA DL 1540 User Manual

IM 701510-01E
13-9
Saving and Loading Data from the SCSI Device
(for DL1520L with suffix code -C4)
13
13.4 Saving and Loading Setting Parameters
1. Following the steps described in section 13.1, select SCSI device as
the media.
Turning ON/OFF the auto naming function
2. Press the “AutoFile” soft key to select “ON” or “OFF”. For more
details concerning this function, refer to the explanation later on.
Saving setting parameters
3. Press the “SETUP...” soft key to display the save/load setting menu
and a list of files.
4. Press the “SAVE” soft key to display the saving menu.
5. Press the “FileName” soft key to display the keyboard.
6. Use the keyboard to enter the filename. For details regarding the
usage of the keyboard, refer to page 4-8.
7. Press the “EXEC” soft key to start saving.
Loading setting parameters
8. Press the “SETUP...” soft key to display the save/load setting menu
and a list of files.
9. Press the “LOAD” soft key to display the loading menu.
10. Use the rotary knob to select the file to be loaded.
11. Press the “EXEC” soft key to start loading.
Rotary knob
Soft keys
STORE/RECALL(FILE) key
SHIFT key
Keys and Procedure
