Standard Accessories
The following standard accessories are supplied with the instrument. Make sure that all
items are present and undamaged.
User's manual (this manual)
Communication interface manual
Operation guide
Printer roll
chart
∗
3

B9850NX
Printer connecting cable
∗
1

(centronics connector to 
D-sub socket)
B9916TB
Power supply fuse
(in fuse holder)
For DL1540/DL1540L,
for suffix code -1 & -5: A1351EF
For DL1520/DL1520L,
for suffix code -1: A1436EF
for suffix code -5: A1349EF
150MHz probe
(10:1, 1:1 selectable)(x2)
∗
2
700998
UL/CSA standard
A1006WD
VDE standard
A1009WD

BS standard
A1054WD
SAA standard
A1024WD
D
F
R
(x1)
(x1)
(x1)
Rubber feet(x4)
A9088ZMx2
Soft case
B9918EZ
Q
Front cover
B9920BT
Power cord (one of the following power cords
is supplied according to the instrument's suffix codes)
SCSI
adapter
∗
4

B9916TD

*1 Supplied with DL1520/DL1520L and suffix code -C3 only.
*2 For DL1540/DL1540L, a total of four passive probes are supplied (if the two optional probes
are included).
*3 A roll chart will be supplied only when the instrument is equipped with a built-in printer.
*4 Supplied only with DL1520L with suffix code -C4.
Checking the Contents of the Package
