IM 701510-01E

16-10

16.11 External Dimensions

Unit : mm

If not specified, the tolerance is ±3%. However, in cases of less than 10mm, the tolerance is ±0.3mm.

Rear View

213

268

215

278

The drawing below shows the exammple for DL1540/DL1540L. 

The external dimensions of DL1520/DL1520L are same too.

295
