IM 701510-01E
16-6
16.7 Communication Interface
For details regarding the GP-IB/RS-232-C interface, refer to the “Communication Interface User’s Manual” (IM 701510-11E).
GP-IB Interface
Comes standard on DL1540/DL1540L. Provided with DL1520/DL1520L with suffix code -
C1, -C3, or -C4.
Item Specifications
Interface GP-IB
Electrical and mechanical Conforms to IEEE St’d 488-1978 (JIS C 1901-1987).
specifications
Interface function SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT0, C0
Protocol Conforms to IEEE St’d 488.2-1987.
Code ISO (ASCII) code
Mode Addressable mode/talk-only mode
Address setting Listener and talker addresses 0 to 30 are settable.
Remote mode clear Remote mode can be cleared by pressing the LOCAL key (except when local lock-out has been set).
RS-232-C Interface
An optional RS-232-C unit is required for DL1540/DL1540L. This interface is provided
with DL1520/DL1520L with suffix code -C2.
Item Specifications
Connector type Half pitch interface cable (DDK : DHA-RB50-S132)
Electrical specifications Conforms to EIA RS-232-C Standard.
Connection format point to point
Communication format full duplex
Synchronizing format Start-stop asynchronous transmission
Baud rate 75/ 150/ 300/ 600/ 1200/ 2400/ 4800/ 9600/ 19200
Centronics Interface
Provided with DL1520/DL1520L with suffix code -C3. This interface is not supported by
DL1540/DL1540L.
Item Specifications
Connector type Centronics interface connector (half-pitch 36 pin), with a printer connecting cable to D-sub socket.
Electrical specifications Conforms to Centronics specifications.
Printers which support ESC/P, LIPS, PCPR201 or PCL5
SCSI (Small Computer System Interface)
Provided with DL1520L with suffix code -C4. DL1540/DL1540L with software (ROM)
version 1.20 or later needs the SCSI interface unit 700930 (sold separately). Not provided
with DL1520.
tem Specifications
Interface standard Conforms to ANSI X3.131-1986 for SCSI (Small Computer System Interface)
Connector shape Half pitch 50 pins (Converting to the pin type is possible with the SCSI adapter accessory)
Electrical specifications Single end, refer to Section 3.3 for pin configurations.
SCSI Devices that can be Used* HD Drives : SCSI HD drives for MS-DOS ver.3.3 or later, or SCSI HD drives that can format in
EZ-SCSI.
MO Drives : 128/230/640 MB drives. MO media uses Semi IBM format.
ZIP Drives
PD Drives
* SCSI devices which can send and receive data over SCSI and which can set the ID number to "5" can be used. There are exceptions as
in the case when the media used on the SCSI device is formatted with another equipment such as a PC, or the pin configuration of the
connector is different. The specifications of each SCSI device are shown above. For more detailed information, contact your nearest
YOKOGAWA representative listed on the back cover of this manual.
To Next Page
