YOKOGAWA DL 1540 User Manual

App-14
IM 701510-01E
Appendix 5 Output Data Format used when Saving Waveform Data (Example DL1540L)
• P-P DATA
P-P (waveform data)
Control information
ASCII Data
ASCII data consists of a mantissa part and an exponent part as shown below.
“Model”, “DL1540L”
“BlockSize”, 512
“BlockNumber”, 1
“DisplayPointNo.”, 6
“DisplayBlockSize”, 500
“TriggerPointNo.”, 250
“Date”, “95/12/01”
“Time”, “18:17:11”
“SampleRate”, 100,”MHz”
“TraceName”, “Ch1”,”Ch2",”Ch3",”Ch4"
“Unit”, “V”,”V”,”V”,”V”
“MediaNo.”, 1
“StartBlockNo.”, 1
“StartPointNo.”, 1
“EndBlockNo.”, 1
“EndPointNo.”, 512
-4.200e+01, -2.000e+00, 2.400e+01, -2.000e+00
-4.200e+01, -2.000e+00, 2.400e+01, -2.000e+00
-4.200e+01, -2.000e+00, 2.200e+01, -2.000e+00
• • • •
• • • •
• • • •
• • • •
• • • •
3.800e+01, -2.000e+00, 2.200e+01, -2.000e+00
3.800e+01, -2.000e+00, 2.400e+01, -2.000e+00
3.800e+01, -2.000e+00, 2.400e+01, -2.000e+00
