YOKOGAWA FX103 User Manual

6-11
IM 04L20A01-01E
Operations for Changing the Displayed Contents
6
Setup Items
Channel Color
• Color
The colors are initially set in the following order for every twelve channels.
• Measurement channels
1: Red, 2: Green, 3: Blue, 4: Blue violet, 5: Brown, 6: Orange, 7: Yellow green, 8:
Light blue, 9: Violet, 10: Gray, 11: Lime, and 12: Cyan
• Computation channels
31: Red, 32: Green, 33: Blue, 34: Blue violet, 35: Brown, 36: Orange, 37: Yellow
green, 38: Light blue, 39: Violet, 40: Gray, 41: Lime, and 42: Cyan
To change the color select from the following 16 colors.
Red, green, blue, blue violet, brown, orange, yellow-green, light blue, violet, gray,
lime, cyan, dark blue, yellow, light gray, and purple.
6.6 Changing the Channel Display Color
