8-11
IM 04L20A01-01E
Computation and Report Function Related Operations (/M1 or /PM1 Option)
8
2. Press the soft key corresponding to the value you wish to select.
The box for the item you changed turns yellow, and the cursor moves to the next
item.
3. Repeat steps 1 and 2 to change the value of all the items you wish to change.
4. Press the DISP/ENTER key to confirm the changes.
The boxes for the items you changed turn from yellow to white, and the cursor
returns to the first item box.
Setup Items
Timer Number and Sum Scale of the TLOG Computation
• First-CH/Last-CH
You can assign channels numbers 31 to 42 as computation channels. Set a range of
channel numbers within this range for setting the timer number and sum scale of the
TLOG computation. The target channels also apply to [Tag], [Rolling average], and
[Alarm delay time] settings.
• TLOG
• Timer No.
Select the timer number from [1], [2], and [3]. If you do not use timer, select the
timer number whose [Mode] is [Off].
• Sum scale
Select the sum scale for calculating the sum (TLOG.SUM) from [Off], [/s], [/min],
and [/h]. The initial value is [Off] (simply compute the sum). You only have to set
the channels that are set to sum computation (TLOG.SUM).
Off: Σ(measured/computed data every scan interval)
/s: Σ(measured/computed data every scan interval) × scan interval
/min: Σ(measured/computed data every scan interval) × scan interval/60
/h: Σ(measured/computed data every scan interval) × scan interval/3600
8.4 Setting the Timer for Statistical Computations (TLOG Computation) and Data Save (TLOG Data)
To Next Page
