App-5
IM 04L20A01-01E
Appendix
App
Table 3 Display data (when acquiring dispaly data and event data)
Number of Number of Measurement Channels
Computation Ch.
1 23456789101112
0 75000 75000 75000 56250 45000 37500 32143 28125 25000 22500 20455 18750
1 75000 56250 45000 37500 32143 28125 25000 22500 20455 18750 17308 16071
2 45000 37500 32143 28125 25000 22500 20455 18750 17308 16071 15000 14063
3 32143 28125 25000 22500 20455 18750 17308 16071 15000 14063 13235 12500
4 25000 22500 20455 18750 17308 16071 15000 14063 13235 12500 11842 11250
5 20455 18750 17308 16071 15000 14063 13235 12500 11842 11250 10714 10227
6 17308 16071 15000 14063 13235 12500 11842 11250 10714 10227 9783 9375
7 15000 14063 13235 12500 11842 11250 10714 10227 9783 9375 9000 8654
8 13235 12500 11842 11250 10714 10227 9783 9375 9000 8654 8333 8036
9 11842 11250 10714 10227 9783 9375 9000 8654 8333 8036 7759 7500
10 10714 10227 9783 9375 9000 8654 8333 8036 7759 7500 7258 7031
11 9783 9375 9000 8654 8333 8036 7759 7500 7258 7031 6818 6618
12 9000 8654 8333 8036 7759 7500 7258 7031 6818 6618 6429 6250
Display Data Sampling Interval
Display update rate 15s* 30s* 1min 2min 5min 10min 15min 20min 30min 1h 2h 4h 10h
(/DIV)
Sampling interval (s) 0.5 1 2 4 10 20 30 40 60 120 240 480 1200
* for the FX103 only.
Event Data Sampling Interval
FX103: 250ms/500ms/1s/2s/5s/10s/30s/60s/120s/300s/600s
FX106: 1s/2s/5s/10s/30s/60s/120s/300s/600s
FX112: 1s/2s/5s/10s/30s/60s/120s/300s/600s
Appendix 1 Time Estimate for Writing Display/Event Data to the Internal Memory
