Lists of Maximum Number of Data Points per Channel
The table below shows the maximum number of data points per channel, per number of
measurement/computation channels to which data is saved. The maximum sampling
length is calculated by multiplying that number by the sampling interval.
For example, when acquiring display data on 3 measurement channels and 3
computation channels only, at a sampling interval of 4 seconds, look up the maximum
number of data points per channel value in table 1 that corresponds to 3 measurement
channels and 3 computation channels (333333) and input that value into the following
equation.
Max. sampling length = 33333 x 4 = 133332 seconds = approximately 37 hours
Table 1 Display data only
Number of Number of Measurement Channels
Computation Ch.
123456789101112
0 100000 100000 100000 75000 60000 50000 42857 37500 33333 30000 27273 25000
1 100000 75000 60000 50000 42857 37500 33333 30000 27273 25000 23077 21429
2 60000 50000 42857 37500 33333 30000 27273 25000 23077 21429 20000 18750
3 42857 37500 33333 30000 27273 25000 23077 21429 20000 18750 17647 16667
4 33333 30000 27273 25000 23077 21429 20000 18750 17647 16667 15789 15000
5 27273 25000 23077 21429 20000 18750 17647 16667 15789 15000 14286 13636
6 23077 21429 20000 18750 17647 16667 15789 15000 14286 13636 13043 12500
7 20000 18750 17647 16667 15789 15000 14286 13636 13043 12500 12000 11538
8 17647 16667 15789 15000 14286 13636 13043 12500 12000 11538 11111 10714
9 15789 15000 14286 13636 13043 12500 12000 11538 11111 10714 10345 10000
10 14286 13636 13043 12500 12000 11538 11111 10714 10345 10000 9677 9375
11 13043 12500 12000 11538 11111 10714 10345 10000 9677 9375 9091 8824
12 12000 11538 11111 10714 10345 10000 9677 9375 9091 8824 8571 8333
Table 2 Event data only
Number of Number of Measurement Channels
Computation Ch.
123456789101112
0 120000 120000 120000 120000 120000 100000 85714 75000 66667 60000 54545 50000
1 120000 120000 120000 100000 85714 75000 66667 60000 54545 50000 46154 42857
2 120000 100000 85714 75000 66667 60000 54545 50000 46154 42857 40000 37500
3 85714 75000 66667 60000 54545 50000 46154 42857 40000 37500 35294 33333
4 66667 60000 54545 50000 46154 42857 40000 37500 35294 33333 31579 30000
5 54545 50000 46154 42857 40000 37500 35294 33333 31579 30000 28571 27273
6 46154 42857 40000 37500 35294 33333 31579 30000 28571 27273 26087 25000
7 40000 37500 35294 33333 31579 30000 28571 27273 26087 25000 24000 23077
8 35294 33333 31579 30000 28571 27273 26087 25000 24000 23077 22222 21429
9 31579 30000 28571 27273 26087 25000 24000 23077 22222 21429 20690 20000
10 28571 27273 26087 25000 24000 23077 22222 21429 20690 20000 19355 18750
11 26087 25000 24000 23077 22222 21429 20690 20000 19355 18750 18182 17647
12 24000 23077 22222 21429 20690 20000 19355 18750 18182 17647 17143 16667
Appendix 1 Time Estimate for Writing Display/Event Data to the Internal Memory
