YOKOGAWA FX103 User Manual

App-17
IM 04L20A01-01E
Appendix
App
Note
• When the measurement and computation channel data enter the condition described in the
following table, status “E” , “O”, and “B” are output in the report.
Data Condition Status
Common to measurement and computation channels
Measurement error or computation error E
For measurement channels
Positive (+) over range O
Negative (–) over range O
Burnout B
For computation channels
Positive (+) computation overflow (when the value exceeds 3.4E + 38) O
Negative (–) computation overflow (when the value falls below –3.4E + 38) O
• Measurement/computation errors are discarded when MAX and MIN are determined.
• Measurement/computation errors, over range, and computation overflow are discarded when
determining AVE and SUM.
• The report output values of AVE ( or INST), MAX, MIN and SUM vary depending on the data
condition of the measurement and computation channels as shown in the table below.
Item Data Condition of Measurement Channels Report Output Value
AVE When all data are measurement errors or over range (Blank)
(Average value)
MAX, MIN, INST • When all data are measurement errors (Blank)
(Maximum value, • Positive (+) over range 99999
minimum value, • Negative (–) over range –99999
instantaneous
value)
SUM • When all data are measurement errors or over (Blank)
(Sum value) range
• When the sum value exceeds 3.4E + 38 9.999999E + 99
• When the sum value is below –3.4E + 38 –9.999999E + 99
Item Data Condition of Computation Channels Report Output Value
AVE When all data are computation errors or over range (Blank)
(Average value)
MAX, MIN, INST • When all data are computation errors (Blank)
(Maximum value, • When the maximum value exceeds 99999999 999999999
minimum value) • When the minimum value is below –9999999 –99999999
instantaneous
value)
SUM • When all data are computation errors or (Blank)
(Sum value) computation overflow
• When the sum value exceeds 3.4E + 38 9.999999E + 99
• When the sum value is below –3.4E + 38 –9.999999E + 99
* The decimal position that was specified when the span for the equation was specified is
reflected in the maximum, minimum, and instantaneous values. For example, if the span
setting of the equation is “200.0,” then “99999999” is output when the value exceeds
“99999999.9” and
“–99999999” is output when the value is below “–999999.9.”
Appendix 5 Data Formats of ASCII Files
