IM 04L20A01-01E 1-31
1
Explanation of Functions
Specifying the Data to Be Acquired
Specify the type of data to be acquired depending on the application. Several
examples are shown below. Please use them as references.
Example 1: Continuously record the waveform data as in the conventional
chart-type recorders.
Select “display data only.”
Example 2: Continuously record the waveform data and when an alarm occurs,
record detailed data around the alarm incident.
Select “display data and event data.” For the event data, select “Trigger” or
“Rotate” for the mode. Specify the trigger used to start the event data acquisition
and the time period during which to acquire the data (event data file size).
Example 3: Continuously record detailed data.
Select “even data only.” Select “Free” for the mode.
Example 4: Recording is not necessary under normal circumstances. Only
record detailed data around the alarm incident.
Select “event data only.” Select “Trigger” or “Rotate” for the mode. Specify the
trigger used to start the event data acquisition and the time period during which to
acquire the data.
1.5 Data Storage Function
To Next Page
