IM 04L20A01-01E 1-49
1
Explanation of Functions
Numerical Display
The range of displayed values of report data is from –9999999 to 99999999 excluding
the decimal point. The decimal point position corresponds to the position of the
decimal point of the lower limit span of the computation channel.
However, special displays are used for cases given in the table below.
• Measurement channel
Item Data Condition of Measurement Channels Displayed value
AVE When all data are measurement errors or over range (Blank)
(Average value)
MAX, MIN, INST • When all data are measurement errors (Blank)
(Maximum value, • Positive (+) over range (including “Burnout”) 99999
minimum value, • Negative (–) over range (including “Burnout”) –99999
instantaneous value)
SUM • When all data are measurement errors or over range (Blank)
(Sum value) • When the sum value exceeds 3.4E + 38 9.999999E + 99
• When the sum value is below –3.4E + 38 –9.999999E + 99
• Computation channel
Item Data Condition of Computation Channels Displayed value
AVE When all data are computation errors or over range (Blank)
(Average value)
MAX,
*
MIN,
*
INST
*
• When all data are computation errors (Blank)
(Maximum value, • When the maximum value exceeds 99999999 999999999
minimum value, • When the minimum value is below –9999999 –99999999
instantaneous value)
SUM • When all data are computation errors or (Blank)
(Sum value) computation overflow
• When the sum value exceeds 3.4E + 38 9.999999E + 99
• When the sum value is below –3.4E + 38 –9.999999E + 99
* The decimal position that was specified when the span for the channel was specified is
reflected in the maximum and minimum values. For example, if the span setting of the
channel is “200.0,” then “99999999” is output when the value exceeds “99999999.9” and “–
99999999” is output when the value is below “–999999.9.”
Storing to the Internal Memory and Saving to the External Storage Medium
For a description on data storage function, see section 1.5 .
1.6 Computation Function and Report Function (/M1, /PM1 Option)
To Next Page
