3-17
IM 04P03B01-01E
Setup Operations for Convenient Functions (Setting Mode)
3
3.12 Setting Up Start Printout and End printout (/BT1 Option)
Explanation
Batch Number
You can enter up to 26 characters.
Lot Number
Enter using a 4 or 6 digit number. Select which number of digits to use (4 or 6) under
“Lot No.” in Basic Setting mode.
Mode
Select Start (
), End ( ), Start 2 ( ), or End 2 ( ). Start
2 and End 2 become available when you enable “Dual comment” in Basic Setting mode.
Comment
You can enter up to 32 characters.
Comment Line Number
1 to 5 lines can be printed out.
Chart Paper Feed Amount
The available setting range is 0 to 50 mm.
Lot Number Update
Update (
): Increments the lot number when recording stops.
Do not update ( ): Do not update the lot number.
Ejection of Pen Offset Compensating Data (pen model)
You can eject the portion that is not recorded when recording stops.
ON (
): Eject
OFF (
): Do not eject
Chart Speed When Ejecting Pen Offset Compensating Data (pen model)
Select the chart speed when ejecting the portion that was not recorded.
Current chart speed (
): Feeds at the specified chart speed.
450 ( ): Fixed to feed at 450 mm/h.
Note
The following operations are performed when using the header printout function (/BT1 option).
• When the power is interrupted and is reintroduced, recording always stops. End
printout/End printout 2 is not performed.
• Until Start printout/Start printout 2 and End printout/End printout 2 finishes, the instrument
cannot transition to the next operation.
• When recording is started, the alarm and message printout information stored in the buffer
prior to recording stop is cleared.
<Related Topics> Enabling start printout and stop printout: Section 4.23
Setting the number of lot number digits and enabling start 2 printout
and stop 2 printout: Section 4.23
