Zebra ZXP 7 series Service Manual

P1036102-007 ZXP Series 7 Card Printer Service Manual 11
Theory of Operation
System-Level Electronics
PCBA Connections
Connector PCBA ID Functional Description
J1 ETHERNET INTERFACE Ethernet Daughterboard
J2 USB_PERIPH_PC USB peripheral interface from host PC
J3 SEN_RIBA Ribbon tri-color sensor (detector)
J4 SEN_RIBB Ribbon tri-color sensor (emitter)
J5 PH_PWR Power to printhead
J6 JTAG RESERVED
J7 DCPWR DC power input to board
J8 MTR_RIBT Ribbon take-up motor
J9 SEN_TENC Ribbon take-up encoder wheel sensor
J10 LAM_CTL Control signals to Laminator or Hopper
J11 SEN_EXIT Exit sensor
J12 -- RESERVED
J13 -- RESERVED
J14 -- RESERVED
J15 -- RESERVED
J16 MTR_MCB Stepper motors driven by MCB
J17 -- RESERVED
J18 USB_HOST_SP RESERVED
J19 USRAUTH User Authentication
J20 BARCD Barcode Reader
J21 OCP Operator Control Panel
J22 MAB Media Authentication Board
J23 SEN_CAM RESERVED
J24 SEN_MCB Various sensors
J25 N/A N/A
J26 UHF/FELICA RESERVED
J27 FDFLIP_CTL Control signals to Flipper Board
J28 FDFLIP_PWR Power to Flipper Board
J29 PH_DATA Printhead Data
J30 USB_HOST_PANEL USB Dual Host cable
J31 -- RESERVED
J32 IP_DEBUG RESERVED
J33 EP_DEBUG RESERVED
J34 SEN_RIBA_NEW Ribbon tri-color sensor (emitter)
J35 SEN_RIBB_NEW Ribbon tri-color sensor (detector)
J36 THERM RESERVED
J50* OPSC SmartCard option board
J51* OPMAG Mag option board
J52* DIAG I/F Diagnostic test
* J50, J51, and 52 are on the bottom side of the Main PCBA

Zebra ZXP 7 series Specifications

General

Print Resolution	300 dpi
Connectivity	USB 2.0, Ethernet
Memory	64 MB standard
Print Technology	Dye-sublimation thermal transfer
Card Capacity	200 cards input hopper, 100 cards output hopper
Card Sizes	CR-80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Power Requirements	100-240 VAC, 50-60 Hz
