228 ZXP Series 7 Card Printer Service Manual P1036102-007
Replacement Procedures for the Laminator
Procedures: Door Assembly (Door and Hinges)
Step 3. From the front of the Laminator: With a TORX T10 driver, remove the two
screws holding the Door Assembly in place.
Step 4. Slide the Door Assembly to the rear, up, and away from the Laminator.
Step 5. Remove the Door Assembly.
Step 6. Ensure the Door is in the closed position.
