Zebra ZXP 7 series Service Manual

244 ZXP Series 7 Card Printer Service Manual P1036102-007
Replacement Procedures for the Laminator
Procedures: Halogen Bulbs
Step 4. Rotate the socket maximum counterclockwise, slide the socket out of the
heater, and move the socket and its associated wires out of the way.
Note • The ceramic end of the Halogen Bulb is visible and accessible.
Caution • Do not touch the glass surface of the replacement bulb. Oil from the fingers
will shorten the bulb’s lifetime.
Step 5. Grasp the ceramic end, slide the bulb out of the heater, and set it aside.

Zebra ZXP 7 series Specifications

General

Print Resolution	300 dpi
Connectivity	USB 2.0, Ethernet
Memory	64 MB standard
Print Technology	Dye-sublimation thermal transfer
Card Capacity	200 cards input hopper, 100 cards output hopper
Card Sizes	CR-80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Power Requirements	100-240 VAC, 50-60 Hz
