Replacement Procedures for the High-Capacity Output Hopper
Procedures: Drive Assembly
Step 5. Disconnect the elevator motor control/power cable from J1 on the PCBA.
J1
Step 6. Disconnect the platen motor control/power cable from J2 on the PCBA.
J2
