350 ZXP Series 7 Card Printer Service Manual P1036102-007
Replacement Procedures for the High-Capacity Output Hopper
Procedures: Base Housing
Step 7. Pull the hopper control cable through the access hole in the base housing.
Installation
Step 1. Route the high-capacity output hopper control cable and ground cable
through the access hole in the base housing.
Step 2. Connect the stacker entry sensor cable to J3 on the PCBA.
