OPERATION
Carl Zeiss Operating the motorized microscope via the touchscreen of the TFT display Axio Imager
144 430000-7344-001 M70-2-0020 e 06/2009
4.8.8 Display page
Using the ◄► buttons on the Display page, the
user can adjust the brightness of the TFT display
and of the light control LEDs..
Pressing the Display off button turns the TFT
display off. Pressing that button a second time
switches the TFT display on again.
To dim the TFT display, press the Display button
on the navigation bar for more than a second.
Touching the TFT display again anywhere switches
the display on again.
After switching the TFT display off, the display returns from the Display page to the page from
which it was activated. This page will be shown after switching the display on again.
Fig. 4-113 Home -> Display
