4.8 Operating the motorized microscope via the touchscreen of the TFT display
4.8.1 Screen layout
On the motorized Axio Imager, the operator can operate and configure the microscope, set it up for
different users and use optional functions via the TFT display. The TFT display is designed as touch-
sensitive screen.
The control elements and information displays are
contained on various, thematically different pages.
Basically, a page on the TFT display is divided into
the following main areas (
Fig. 4-20).
4.8.1.1 Navigation button bar
The navigation button bar at the left edge of the
screen contains buttons via which you can activate
all pages. The buttons available depend on the
currently displayed page. However, the following
buttons are accessible on all pages:
− Home Activates the start page
− Favorites Calling up the favorites page
− Display Activates the display page
4.8.1.2 Status line
The status line on the lower edge of the screen
furnishes information on the current settings of
the:
− objective nosepiece,
− reflector turret,
− condenser,
− lamp voltage or intensity,
− switch status of the internal power
supply.
Pop-up windows are not shown on the status line
Control area
N
a
v
ig
a
t
io
n
b
u
t
t
o
n
b
a
r
Navigation status bar
Fig. 4-20 Main areas of TFT display
