2.3 Equipment and compatibility table
Type of Stand
Component Option
A2
LED
A2 M2p M2 D2 Z2
A2
m
M2
m
D2
m
Z2m
Manual + + - - + - + - + -
Stand
Motorized
- - + + O* + - + O* +
Coding PC readable + + + + + + + + + +
Coded O O O O O O O O O O
Tube lens turret
Motorized
- - O O - O - O - O
6 positions, coded O O O O O O O - O O
6 positions, motorized - - O O O O - + O O
6 positions, motorized ACR - - - - - O - - - O
Reflector turret
10 positions, motorized
ACR**
- - - - O O - - O O
6 positions, coded POL O O - O O O O O O O
6 positions, coded HD DIC O O - O O O O O O O
6 positions, motorized HD
DIC
- - - O - O - O - O
6 positions, motorized HD
DIC ACR
- - - O - O - O - O
7 positions, coded HD O O + O O O O O O O
Objective nosepiece
7 positions, motorized HD - - - O - O - O - O
Manual O O O O O O O O O O Modulator turret for
C-DIC/TIC
Motorized*****
- - - O - O - O - O
Modulator turret for
transmitted-light DIC
Motorized***** - - - - - O - - - O
Attachable stage carrier with
condenser carrier
0 mm – 25 mm
+ + + + + O O O O O
Attachable stage carrier for
detachable condenser carrier
0 mm – 45 mm
O O O O O O O O O O
Attachable reflected-light
stage carrier
0 mm – 63 mm O O O O O O O O O O
Manual - + - - + - O O O O
Transmitted-light illumination
Motorized
- - - + - + - - - O
Transmitted-light LED - + O + O O O O O O O
Manual - + - O O O O O O O
Two-position transmitted-light
filter wheel
Motorized
- - - O - O - - - O
Manual*** O O O O O O + - + -
Reflected-light illumination
Motorized***
- - - - - O - + - +
Manual O O O O O O + O + O
Reflected-light luminous-field
diaphragm
Motorized
- - - - - O - O - O
