Zeiss Axio Imager - Page 18

INSTRUMENT DECRIPTION
Carl Zeiss Equipment and compatibility table Axio Imager
18 430000-7344-001 M70-2-0020 e 06/2009
Type of Stand
Component Option
A2
LED
A2 M2p M2 D2 Z2
A2
m
M2
m
D2
m
Z2m
Manual O O O O O O O O O O
Reflected-light aperture
diaphragm
Motorized
- - - - - O - O - O
Manual O O O O O O O O O O
Reflected-light two-position
filter wheel
Motorized
- - - O - O - O - O
Manual O O O O O O O O O O
FL attenuator
Motorized
- - - - - O - O - O
Manual + + - - + - + - + -
Reflected light / transmitted
light selection
Software
- - + + - + - + - +
Manual + + - - + - + - + - Mixed light
with extra power supply
Software
- - + + - + - + - +
Manual + + - - + - + - + -
Motorized, 25 nm - - + + - - - + - -
Focus (z-axis)
High-performance focus
(motorized, 10 nm)
- - - - - + - - - +
TFT display - - - O + - + - + - +
Apotome - O O O O O O O O O O
External - - + + - + - + - +
Power supply
Internal
+ + - - + - + - + -
Mechanical CAN stages Motorized**** O O O O O O O O O O
Piezo O O O O O O O O O O
Scanning stages
DC / stepper motors
O O O O O O O O O O
With manual stage O O O O O O O O O O
Fast z-piezo operation
With scanning stage
O O O O O O O O O O
Motorized 2TV tube - - - O O - O - O - O
Manual O O O O O O O O O O
Condensers
Motorized
- - O O - O - O - O
+ = Included in stand
O = Optionally available
O* = Included only, if equipped with Light Control Mot. 430000-9304-000
- = Not possible
* = Motorized (6-position and 10-position) reflector turret may be used.
** = ACR function not available with Axio Imager D2 and D2m.
*** = All reflected-light illumination systems come with a motorized shutter.
For fluorescence applications, it may be optionally replaced by a high-speed shutter.
**** = USB/CAN converter 432909 is required for use on Axio Imager A2 LED, A2, A2m, D2 and D2m.
***** = Motorized only if used with an objective nosepiece.
